FEATURES
- Max lift capacity: 5 ton
- Adjustable lift height: 1890~1930 mm
- Telescopic 2 stage lifting pads
- Lifting time: 35 sec
- Lowering time: 30 sec
- Motor: Hydrotek Korean 415V 50Hz 3 PH 2.2 KW (standard) or Optional 240V
- Pressure rating: 18MPA
- Asymmetric arm for wider space
- Safety lock & tool trolley on the arm
- Manual lock release
- Load pad extension adaptor for 4x4
For any spare parts call: (02) 9671 7811
Enquiry
Capacity |
5000kg |
Max Height |
1890 ~ 1930 mm |
Hoist Max Height |
3750 mm |
Lowering Time |
30~45 sec |
Overall Width |
3440 mm |
Dimension (LxWxH) |
2726 x 3440 x 3750 mm |
Net Weight |
700 kg |
Motor |
(Standard) 3 phase or (Optional) 240V single phase |
