FEATURES
- Dual hydraulic
- Rams with chain design
- Asymmetric design
- 3 stage front arm
- Dual wire structure makes perfect synchronization
- Automatic arm locking device
- Automatic Electrical Locking System
- 2 stage load pads
- Powder coat finish
- Optional 4WD load arm adapters
For any spare parts call: (02) 9671 7811
Enquiry
Capacity |
4000kg |
Max height |
1870 ~ 1950 mm |
Pad Stool Height |
130 ~ 210 mm |
Hoist Max Height |
2795 mm |
Drive-Thru Clearance |
2855 mm |
Overall Width |
3410 mm |
Motor |
(Standard) 3 phase or (Optional) 240V single phase |
