FEATURES
- Compatible to handle heavy vehicles with extended height and width
- Dual packing hydraulic cylinders for ultimate power & stability
- Engineering plastic carriage guide
- 3 different height adjustment of rubber supporting pad
- Dual wire structure makes perfect synchronization
- Automatic arm locking device
- Automatic electrical locking system
- Cable remote control included
- Direct lowering button
- OPTIONAL: 4WD load arm adaptors available
- OPTIONAL: outriggers set available to increase stability
- OPTIONAL: 1 meter extra height kit available
For any spare parts call: (02) 9671 7811
Enquiry
| Capacity |
5000kg |
| Max height |
1920 ~ 1975 mm |
| Min height |
100 ~ 155 mm |
| Hoist Max Height |
3860 mm |
| Drive-Thru Clearance |
2860 mm |
| Lifting time |
35s |
| Lowering time |
35s |
| Overall Width |
3428 mm |
| Motor |
(Standard) 3 phase or (Optional) 240V single phase |
