FEATURES
- Dual packing hydraulic cylinders for ultimate power & stability
- 3 different height adjustment of rubber supporting pad
- Dual wire structure makes perfect synchronization
- Automatic electrical locking system
- Cable remote control included
- Direct lowering button
- Fast power pack takes only about 30 seconds to lift up
- OPTIONAL: 4WD load arm adaptors available
- OPTIONAL: outriggers set available to increase stability
- OPTIONAL: 1 meter extra height kit available
For any spare parts call: (02) 9671 7811
Enquiry
Capacity |
4500kg |
Max height |
1820 ~ 1875 mm |
Min height |
100 ~ 155 mm |
Lifting time |
30s |
Lowering time |
30s |
Motor |
(Standard) 3 phase or (Optional) 240V single phase |
Operation |
Control panel push buttons & cabled remote control |
